Dualsky ECO Series 2208C 980KV 1200KV 1450KV 1770KV Brushless Outrunner Motors







Dualsky ECO series brushless outrunner motors cover the RC power market which is less than 900W.

ECO is positioning high quality and low price, which is suitable for the beginner and mid-level pilots of fixed wing aircrafts and multi rotors.

ECO series adopt new naming rule, name the motor according to the stator diameter and the length of the magnet

Fashionable packaging design.

Description:
Brand: Dualsky
Item: ECO Series 2208C Brushless Outrunner Motors
KV: 980KV/ 1200KV/ 1450KV/ 1770KV (Optional)
Usage: For RC Airplane

ECO-C Series ECO 2208C Item NO. 51351 51352 51353 51354 RPM/V(KV) 1770 1450 1200 980 Shaft diameter 3.2 3.2 3.2 3.2 Mountingholes pitch 16/19 16/19 16/19 16/19 Weight (g) 44 44 44 44 Resistance (mOhm) 64 90 134 199 Idle Current @ 10V (A) 1.10 1.03 0.64 0.48 No. of Cells (LiPo) 2..3 2..3 2..3 3..4 Max. Efficiency Current (A) 15 12 11 10 Max. Burst Current (15S) [A] 20 16 15 14 Max. Power (15S) 210W 150W 150W 150W Input Connectors (mm) 3.5 3.5 3.5 3.5 Recommended ESC XC-22-Lite XC-12-Lite XC-12-Lite XC-12-Lite Prop. Range APC7x5E 7x3..8x5 7x4..9x5 8x4..10x5 App. Class Wings and Little Jets
400-600g, 300 Class

Features:

Based on the system of CA2, highlighting the price performance

Designed for airplane model

Provide rich KV choices and part of the KV is also suitable for multi rotors

Power ranging from the indoor model to the 50E model planes

Choose high quality silicon steel sheet material and ball bearing, working stability

Easy to install in two ways: installation after the fire prevention (the glider) and before fire prevention (aerobatic plane)

The whole aluminum alloy CNC machining and anodized

The marks are laser marked, not affect the dynamic balance

Standard wire length and pre-soldered plugs

The accessories include propeller mount, gold plugs, mount and screws

Dualsky ECO Series 2208C Brushless Outrunner Motors

Package Included:
1X Dualsky ECO Series 2208C Brushless Outrunner Motors
1X propeller mount
1X gold plugs
1X mount
1X screws
