DSSERVO DS3225 25KG Metal Gear High Torque Waterproof Digital Servo For RC Airplane Robot

The DSSERVO DS3225 25KG digital servo features HV high torque, metal gear, fast heat dissipation, sensitivity and responsiveness. With high quality and performance, it is tailored for RC hobbyist to provide different experience and delight.

Features:

Large torque - maximum torque can up to 25kg.cm (6.8V)

High-precision metal gear with hard anodizing for better accuracy and longer service life

CNC aluminium middle shell enhances heat dissipation and ensures the servo motor can work well

Water proof rubber seals screws, made of first-grade material ensure the longevity of the products

Good performance digital standard servo, which can be a common use for robots, mechanical arms, climbing cars and remote control toys

Great choice for university professors and students who are interested in developing software for robot parts

Tailored for RC hobbyist to provide different experience and delight

Specifications:

Brand: DSSERVO

Item: DSSERVO DS3225 Digital Servo

Operating voltage: 4.8 - 6.8V

Operating speed ( 5.0V ): 0.15 sec/60 degree

Operating speed ( 6.8V ): 0.13 sec/60 degree

Stall torque ( 5.0V ): 21kg/cm

Stall torque ( 6.8V ): 25kg/cm

Dead band: 3μs

Working frequency: 50-333Hz

Connector wire: About 300mm

Gear type: Metal

Motor Type: DC motor

Size: 40 * 20 * 40.5mm

Weight: 67g

Note: There could be some deviations due to manual measurement or slight color difference as the result of shooting scene

Package Included

1 x DS3225 25kg Digital Servo

1 x 25T Adjustable Metal Servo Arm
