DIY Assemble 2205 2-4S Brushless Motor 0.42*2.8 Copper Wire with Motor Cap Banana Plug
Test Table:
Voltage (V) Current (A) Pull (g) Power (W) EFP (g/W) Propeller 12 1.0 65 12.000 5.417 5045 3-Blade 12 3.0 175 36.000 4.861 5045 3-Blade 12 5.0 288 60.000 4.800 5045 3-Blade 12 7.0 372 84.000 4.429 5045 3-Blade 12 9.0 455 108.000 4.213 5045 3-Blade 12 11.0 525 132.000 3.977 5045 3-Blade 12 13.0 585 156.000 3.750 5045 3-Blade 12 15.0 652 180.000 3.622 5045 3-Blade 12 17.6 731 211.200 3.461 5045 3-Blade 12 19.0 748 228.000 3.281 5045 3-Blade 12 20.4 762 244.800 3.113 5045 3-Blade
Specification:
Item Name: DIY Assemble 2205 Brushless Motor
Configu ration: NP
KV: 2500
Height: 18.9mm
Width: 28mm
Shaft diameter: M5
Motor mount hole size: M3
Copper Wire: 0.42MM ( Diameter)*2.8M (Length)
No-Load Current: 1.2A
No-Load Current: 1.2A
Battery: 2-4S lipo battery
Internal resistance: â¦
CW screw thread motor comes with Siliver cap
CCW screw thread motor comes with Black cap
Package Included:
1x Assemble 2205 Motor
1x Cap
1x Banana Plug for Motor
