DIY Assemble 2204 2-3S Brushless Motor 0.42*2.8 Copper Wire with Motor Cap Banana Plug
Test Table:
Voltage (V) Current
(A) Pull
(G) Power
(W) EFP
(g/w) Propeller 11V 2.0 130 22.000 5.909 5045 3-Blade 11V 5.0 270 55.000 4.909 5045 3-Blade 11V 6.0 320 66.000 4.848 5045 3-Blade 11V 8.0 400 88.000 4.545 5045 3-Blade 11V 10.0 465 110.000 4.227 5045 3-Blade 11V 12.0 530 132 4.015 5045 3-Blade 11V 15.0 630 165 3.818 5045 3-Blade
Specification:
Item Name: DIY Assemble 2204 Brushless Motor
Shaft diameter: M5
Motor mount hole size: M3
Weight: 25 grams
Voltage: 2-3S
Battery: 2-3S lipo battery
Copper Wire: 0.42MM ( Diameter)*2.8M (Length)
Copper Wire: 0.42MM ( Diameter)*2.8M (Length)
Internal resistance: â¦
Usage: for 250 260 280 Multirotor Frame Kit
CW screw thread motor comes with red cap
CCW screw thread motor comes with black cap
Package included:
1 x DIY Aseemble 2204 Motor
1 x Motor Cap
1 x Copper Wire
1x Banana Plug
1 x Motor Cap
1 x Copper Wire
1x Banana Plug
