Diatone V8.3 LC Filter Power PDB Board HUB Low Ripple Current Series For RC Multirotors

Description:
V8.3 Power HUB based on V7.3 changed the ESC solder tabs direction to make the ESC and battery solder pad be 90 degree, more suitable for X-type multirotor. The both-sides soldering way also suit H-type multirotor and no need to dismount the upper board, quite convenient to solder. 36X36mm size is easy to connect to flight controller. 4-layers PCB guarantees the 20A ESC’s steady working. 2 sets BEC circuit meanwhile can use servos, video transmitters, LEDs, moreover, V8.3 added the ESC signal channel, easy soldering and neat wiring. Support 3-6S (11.1V-22.2V). The HUB also features convenient solder bridge of various voltage for camera & video transmitter.
The new LC filter circuit uses superior filter inductor and 47uf tantalum capacitor, 1A electrical load 5V ripple just only 31mV, 12V ripple just only 63mV, camera and video transmitter gain purer power source.

Features:
Both-sides soldering ESC, convenient to use
2oz copper & 4-layers PCB
Low Ripple current
ESC & Battery solder tabs in pairs.
Solder Bridges of various voltage for Camera & VTX.
DC/DC synchronous buck regulator, Efficiency is up to 95%.
5V & 12V Output LED indicators & Short circuit tolerant.

Specification:
Working Voltage: 3~6S LiPo (11.1-22.2V)
Output Voltage: 5V&12V
Output Current: 2A
ESC outputs: 4
Current output:4*20A
Size: 36*36mm
Weight: 5.5g
Mounting: 30.5mm / Φ3mm

Package included:
1 x Diatone V8.3 PDB
1 x Cable
