Dasmikro FLYSKY 8CH 2.4Ghz RC Micro Receiver With Failsafe 1mm JST Socket

PAY ATTENTION TO JST CABLE COLOR!



Description:

There is no bind pin designed, the receiver has an "auto-bind" procedure. When switch on, receiver tries to bind with transmitter for about 3s (led is blinking). If receiver find a transmitter (must be also in bind mode) then it records transmitter identifier and works with it. If it can't bind with a transmitter then is retrieves previously bind transmitter identifier and works with it. This way, you save an extra pin and just need to bind only once. After bind procedure, If reception is ok then led if on, if no reception at all led if off, if reception if bad led is blinking randomly.

Important Feature:
This receiver is designed with failsafe function. Bridge the safe mode learn contact will record CH1-CH8 current position and the receiver will out put the recorded positions when it is in failsafe mode.

Technical Data:
Brand Name: Flysky
Frequency: 2.4G
Channel: 8CH
Net Weight: 2g
Operating Voltage: 1S~3S
Failsafe: Yes
Size: 28*21*5mm

Optional "8 Channel Servo Signal" (A)or "7 Channel Servo Signal + PPM"(B)
Option A: 8 channel servo signal output CH1 to CH 8
Option B: 7 channel servo signal output CH1 to CH7, CH8 output PPM signal

Applicability:
Flysky T6, TH9X, I6
Gun-type remote control: Flysky GT2B, GT3, GT3B, GT3C etc.
ER9X,OPENTX, Walkera D7E, D10 with Deviation firmware and A7105 module etc.

Package Included:
1 x FLYSKY 2.4G Ultra Miniature 8CH Receiver
10 x 1mm JST Plug with cable
