Dasmikro Flysky 8CH 2.4Ghz RC Micro Receiver For Multiple Models Control With Failsafe 1mm JST Socket

PAY ATTENTION TO JST CABLE COLOR!



Description:
There is no bind pin designed, the receiver has an "auto-bind" procedure.
When switch on, receiver tries to bind with transmitter for about 3s (led is blinking).
If receiver find a transmitter (must be also in bind mode) then it records transmitter identifier and works with it.
If it can't bind with a transmitter then is retrieves previously bind transmitter identifier and works with it.
This way, you save an extra pin and just need to bind only once.
After bind procedure, If reception is ok then led if on, if no reception at all led if off, if reception if bad led is blinking randomly.

Important Feature:
This receiver is especially designed for RC model multiple control.
It use CH8 signal to select specific model. Use one transmitter to bind several receivers and set the receivers to different CH8 positions.
When CH8 signal is changed to the specific position, the specific model will be activated, the CH1-CH7 will output the normal servo signal.
The rest receivers will be in standby mode and output the predefined safe mode channel positions.
Bridge the safe mode learn contact will record CH1-CH8 current position and the receiver will out put the recorded positions when it is in actually failsafe or standby mode.

Technical Data:
Brand Name: Flysky
Frequency: 2.4G
Channel: 8CH
Net Weight: 2g
Operating Voltage: 1S~3S
Failsafe: Yes
Size: 28*21*5mm

Applicability:
Flysky T6, TH9X, I6
Gun-type remote control: Flysky GT2B, GT3, GT3B, GT3C etc.
ER9X,OPENTX, Walkera D7E, D10 with Deviation firmware and A7105 module etc.

Package Included:
1 x FLYSKY 2.4G Ultra Miniature 8CH Receiver
10 x 1mm JST Plug with cable
