Dasmikro Flysky GT3C Transmitter 6 Channel 8 Channel Customized

Description:


Customized 8 Channel FLYSKY GT3C RC Transmitter. Add maximum 6 extra channels to GT3C. It could bind with FLYSKY 3CH, 6CH and 8CH receivers.

Brand Name: Flysky
Item Name: Customized 8CH FS-GT3C Transmitter Remote Control
Weight: 350g
Color: black
RC Parts & Accs: Transmitters
Color random send
Specifications:
Channels: 8 Channels
Model type: car/boat
RF range: 2.40-2.48GHz
Bandwidth: 500KHz
Band: 160
RF power: less than 20DB
2.4G system: AFHDS
Code type: GFSK
Sensitivity: 1024
Low voltage warning: yes(less than 3.5V)
DSC port: yes(USB;output:PPM)
ST range: 90
TH range: 45(F:30,B:15)
Charger port: yes
ANT length: 26mm
Power: 3.7V(800mAh)
Size:157*116*258mm
Color: Black/Orange/Gray
Certificate:CE0678,FCC

Option:
Option A: 6 Channel
It uses 4 channel PPM expander PCB and keep the first channel and the second channel, add 4 channels from channel 3 to channel 6, in this case you could bind FLYSKY 6CH receiver to use all 6 channels. (channel 1 and channel 2 are from GT3C original, channel 3 and channel 4 are 3 position toggle switch, channel 5 and channel 6 are potentiometers.

Option B: It uses 4 channel PPM expander PCB and the third channel, add 4 channels from channel 4 to channel 7, in this case you could bind FLYSKY 8CH receiver to use all 7 channels. (channel 1, channel 2 and channel 3 are from GT3C original, channel 4 and channel 5 are 3 position toggle switch, channel 6 and channel 7 are potentiometers.

Option C: It uses 6 channel PPM expander PCB and keep the first channel and the second channel, add 4 channels from channel 3 to channel 8, in this case you could bind FLYSKY 8CH receiver to use all 8 channels. (channel 1, channel 2 are from GT3C original, channel 3, channel 4 and channel 5 are 3 position toggle switch, channel 6 , channel 7 and channel 8 are potentiometers.)

Package Included:
1 x Customized 8 channel FLYSKY GT3C RC transmitter
