DALRC 5V / 12V 3A Mini Power HUB/BEC PCB/PDB Power Distribution Board

The Mini POWER HUB been engineered to provide the highest possible performance and reliability in a 36*36mm&4 layers PCB.
The HUB distributes power from a battery pack to 4 ESCs.as well as provding synchronised & regulated DC outputs for powering cameras,
servos, video transmitter, LEDs, ect. Batteries may range from 3S to 6S Lipo. The HUB also features convenient solder bridge of various
voltage for camera & video TX.


Specifications:
Brand name: DALRC
Item name: Power Distribution Board

Ceneral
input voltage range (2s-6s operation): 7-26V DC
Regulated 5V and 12V outputs
LED power indicators (5V & 12V outputs)
4 ESC outputs

ESC outputs:
continuous current: 50A per output
Peak current (5 seconds/minute): 200A per output

BEC 5V output:
Designed for RC receivers, flight controllers, OSD, and Servos
DC/DC synchronous buck regulator, Efficiency is up to 95%
Voltage: 5.0 +/- 0.1VDC
Continuous current: 3 Amps
Short-circuit tolerant(10 seconds/minute)
LED (indicates voltage is in regulation)

BEC 12V output:
The battery should be 4S-6S Lipo
Standard output designed to power cameras and video transmitters,etc.
Voltage: 12.0 +/- 0.2VDC
Continuous current: 2 Amps (Max.3A 10s/minute)
Short-circuit tolerant(10 seconds/minute)
LED(indicates voltage is in regulation)

CAM & VTX voltage bridge
3S operation. choose "VCC" for 12V camera & 12V VTX, VCC=Battery voltage.
4-6S operation, choose "5" for 5V camera
Video pass through from the "CAM" pad to the "VTX" pad

Physical
Dimensions: 36x36mm
Weight: 8g
Mounting holes 30.5mm square spacing

Feature:
3oz coppter & 4-layers PCB
ESC & Battery solder tabs in pairs
Solder Bridges of various voltage for camera & VTX
5V & 12V Output LED indicator & Short circuit tolerant

Package Included:
1 X Board
