CYS-S0006 Mini Micro Analog Servo is suitable for indoor slow flyers, electric park flyers, RC electric 3D airplanes (Shockflyer, Blitz, etc.) and micro electric RC helicopters. It is designed for most brands of radio equipment including JR, Futaba, GWS, Airtronics & Hitec. And its high strength design increase its durability. If you want to get a better RC playing experience, CYS-S0006 servo is a good choice!

Features:

Wide operating voltage-4.8V to 6V

Small size: 21.5 * 11.8 * 22.7mm, light weight: about 6g

Perfectly tailored to micro RC Car, RC Boat, RC Airplane

Stall torgue of 1.0kg.cm (13.89oz / in) / 1.2 kg.cm (16.67oz / in)

Smooth movement, powerful torque and exquisite workmanship

Specifications:

Brand: CYS

Model: CYS-S0006

Name: CYS-S0006 Analog Servo

Dead Band: 5μsec

Operating Voltage: DC 4.8-6.0V

Operating Speed (4.8V): 0.14sec / 60 degrees

Operating Speed (6.0V): 0.12sec / 60 degrees

Stall Torque (4.8V): 1.0kg.cm (13.89oz / in)

Stall Torque (6.0V): 1.2 kg.cm (16.67oz / in)

Running Current(4.8V): 120mA

Running Current(6.0V): 140mA

Stall Current(4.8V): 390mA

Stall Current(6.0V): 460mA

Idle Current(4.8V): 10mA

Idle Current(6.0V): 10mA

Weight: 6g

Dimensions: 21.5 * 11.8 * 22.7mm

Note: There could be a few deviations due to manual measurement, thank you for your attention

Package Included

1 x CYS-S0006 Servo

1 x Spare Parts Set
