Cobra Champion Series 2205 CP2205 2300KV 2500KV 3-6S Brushless Motor For 210 250 FPV Racing Frame - 18.99 €

Cobra Champion Series 2205 CP2205 2300KV 2500KV 3-6S Brushless Motor For 210 250 FPV Racing Frame
Seller: Banggood,
Free shipping aviable, Registered postage from 25 €


Cobra Champion Series 2205 CP2205 2300KV 2500KV 3-6S Brushless Motor For 210 220 250 FPV Racing Frame








Description:
Brand: Cobra
Item name: CP2205 2300KV 2500KV Brushless Motor
Stator diameter: 22.0 mm
Stator thickness: 5.0 mm
Number of stator slots: 12
Number of magnet poles: 14
Motor wind: 22
Motor KV value: 2300/2500
Motor weight: 29 grams
Outside diameter: 28 mm
Motor shaft diameter: 3.00 mm
Body length: 16.1mm
Overall shaft length: 33.6 mm

2300KV:
No load current: 0.66 Amps @ 8 Volts
Motor resistance (Rm) per Phase: 0.084 Ohms
Motor resistance (Rm) Phase to Phase: 0.056 Ohms
Maximum continuous current: 23 Amps
Max continuous power (3-cell Li-Po): 245 Watts
Max continuous power (4-cell Li-Po): 325 Watts

Tested table about CP2205 2300KV motor :


Features:
The Cobra Champion series motors are the most powerful versions ever made for FPV Racing! A completely new design that increases cooling and efficiency, these motors provide the ultimate power for your FPV Racing Quads. The stators are made with 0.20mm laminations for maximum efficiency and minimum Eddy Current losses. Since these motors are typically soldered directly to the speed controller to save weight, the CP-2205 motors come without bullet connectors ,and feature extended pre-tinned motor leads that are 2-1/4 inches (55mm) long. These motors also have 3mm threaded holes in a 16x19mm pattern on the back plate for easy installation on your model.
The CP-2205 series motors feature an integrated 5mm threaded motor shaft which eliminates the chance of having a prop adapter spin off in flight. The included nylon insert prop nut, which has an integrated prop washer, provides a solid attachment for your propellers that will not loosen up and slip during use.
Also included with every Cobra CP-2205 Series Motor is a complete accessory pack, which includes everything you need to securely mount the motor to your quad frame, and to mount the prop to the motor.
Package included:
1 x Cobra CP2205 Brushless Motor
1 x Flange style Self-locking prop nut with nylon insert
4 x M3 flat washers
4 x M3*6 Hexagon socket head screw
