CK Racing F3 Deluxe 10DF Flight Controller For RC Multirotors Supports OneShot ESC
Description:
Six-Axis: MPU6050
Compass: HMC5883L
Barometer: MS5611-01BA
Size: 35*35*5mm
Weight: 6 grams (no headers, 8 grams with)
Processor: STM32F303CCT6
Processor: STM32F303CCT6
Features:
Better coding practices and introducing tests, easier to maintain and for future development. (Dominic has software development background)
Many bugs fixed from Baseflight.
Supports more flight controllers, including CC3D, CJMCU and Sparky.
Supports OneShot ESC and more than 8 RC channels.
Additional PID controllers that uses floating point arithmetic operations. (now has 3 built-in PID Controllers)
Many more features such as RGB LED strip support, Autotune, In-flight PID tuning with your radio, blackbox flight data logging etc.
Flight Performance: The SPR F3 builds on tried and tested software, processor and sensor technology to make your aircraft fly like it's on rails.
No-Compromise I/O: Use all the features all the time; e.g. Connect your OSD + SmartPort + SBus + GPS + LED Strip + Battery Monitoring + Sonar + 8 motors - all at the same time!
Configurable: The SP F3 runs Cleanflight which can be configured to suit your needs using a cross-platform GUI (Windows/OSX/Linux).
Tiny and lightweight: The Racing F3 has a standard 36x36mm form-factor with 30.5mm mounting holes and weighs just 6 grams.
Flight Logging: On-board high-capacity black box flight log recorder - optimize your tuning and see the results of your setup without guesswork.
Next-Generation CPU: The RacingF3 has an ARM Cortex-M4 72Mhz CPU with Math co-processor (FPU) for efficient flight calculations that gets more done in less time.
Loop times up to ~2x as fast as previous-generation STM32F1 based boards.
Developer Friendly: Developer friendly debugging port (SWD) and boot mode selection, unbrickable bootloader.
OneShot ESC: Full support for OneShot ESCs for easy PID tuning and a sharper response.
Broad RC receiver Support: Supports SBus, SumH, SumD, Spektrum1024/2048, XBus, PPM, PWM receivers. No external inverters required (built-in).
Programmable LED: Dedicated output for programmable LEDs - great for orientation, racing and night flying.
Battery Monitoring: Battery monitoring ports for voltage and current.
Sonar: Sonar support for precision low-altitude hold.
I2C Port: I2C port always powered, perfect for external sensors or always-on OLED Screen.
Buzzer: Buzzer port for audible warnings and notification
Package included:
1 x F3 Flight Controller(USA direct only this one)
2 x 8p Wire Rod
2 x 8p Wire Rod
2 x 4p Extension Path
8 x Pins set
