Caddx Freestyle Version Turbo Micro SDR2 Plus 1200TVL Super WDR OSD 16:9/4:3 Switched FPV Camera - 29.00 €

Caddx Freestyle Version Turbo Micro SDR2 Plus 1200TVL Super WDR OSD 16:9/4:3 Switched FPV Camera
Seller: Banggood,
Free shipping aviable, Registered postage from 25 €


Caddx Freestyle Version Turbo Micro SDR2 Plus 1200TVL Super WDR OSD 16:9/4:3 NTSC/PAL Switched Mini Camera

Specification

Model Turbo micro SDR2 plus (Freestyle version)
Image Sensor 1/2.8" SONY Exmor-R STARVIS sensor
Horizontal Resolution 1200TVL
TV System NTSC & PAL (changeable)
IMAGE 16:9 & 4:3 (changeable)
WDR Super WDR (Double Scan)
Min. Illumination [email protected] (Starlight)
Lens Full Size Turbo Eye Lens
Synchronization Internal
Electronic Shutter PAL: 1/50~100,000; NTSC: 1/60~100,000
S/N Ratio >60dB (AGC OFF)
Video Output CVBS
Camera OSD ADVANCE MENU
DNR 3-DNR
LANGUAGE ENG/FRANCE/RUS/SPA/PU/KOREA/CHN/JAPAN
Day/Night Auto/Color/B&W/EXT
Dimensions 19mm*19mm*19mm
Wide Power Input DC 5-40V
Work Temperature -20℃~+60℃
Work Humidity 20%~80%
Weight 5.5g (N.W.)/ 40.5g (G.W.)


Packing List
1 x Camera
1 x Aluminum bracket
1 x 5D-OSD menu board
1 x 4pin FPV silicone cable A (extend into a 2pin joint for OSD board and a 3pin joint for FPV)
1 x FPV silicone cable B (2-pin port for both side)
1 x Internal hexagonal wrench
1 x Screws set
