Betaflight 3.1.0 Revo F4 Flight Controller Integrated Compatible Frsky D8 Receiver 20x20mm Built-in 5V BEC
Description:
Item name: F4 FC Integrated Frsky Receiver
Size: 27x27mm
Mounting hole: 20x20mm, φ2.5mm
Weight: 3g
Firmware: betaflight_3.1.0_REVO
Input voltage: 2-4S
Master control: STM32F405RGT6
Sensor: MPU6000
Connector: LED_STRIP
Buzzer port: with
Blackbox: 128Mb Flash(16M Byte)
BEC: Built-in 5V 1A BEC
OSD function: no
Integrated Frsky D8 protocol receiver, SBUS signal.
Supports Oneshot125, Oneshot42, Multishot, Dshot150, Dshot300, Dshot600 ESCs.
Binding method:
(Take the X9D remote control as an example, select the D8 mode.)
1. Press the BIND key on the receiver and power it, the green indicator LED on the receiver will normally on.
2. Set the remote control under BIND mode, the green indicator LED on the receiver goes off manifests binding successfully. Set the remote control beside BIND mode.
3. Power the flight controller again, the green LED is normally on manifests the signal received successfully; the green LED is flashing manifests lost of signal or binding unsuccessfully.
Package included:
1 x F4 FC Integrated Frsky Receiver
