Specification:
Flight controller
CPU: STM32F411CEU6
Sensor: MPU-6000 three-axis accelerometer / three-axis gyroscope (SPI connection)
Power supply: 1-2S battery input (DC 3.2V-8.4V)
BEC: Built-in buck-boost circuit (1S input BEC output 0.5A, 2S input BEC output 1.5A)
Receiver: PPM, SBUS, IBUS, Spektrum DSM2/DSMX, 1024/2048.
Built-in OSD interface
Support BLheli suite ESC programming
Support DHSOT ESC
Built-in voltage detection
Board size: 28.5*28.5MM
Screw hole spacing: 24.5*24.5MM diameter 3.0MM
Board weight: 3.2 g
Brushless ESC
Power supply: 1-2S
Current : 10A continuous peak 12A (for 2 seconds)
Support BLHeliSuite programmable
Factory firmware: S_H_50_REV16_7.HEX
Signal support: D-shot150, D-shot300, D-shot600, Oneshot125, Multishot, PWM
Note: When inputting SBUS/IBUS and DSM receivers, configure RX2 as the input interface.
Package Included:
1 x BeeCore F4 Flight Controller
1 x Power Cable
