AX215 V2 215mm / 230mm Wheelbase 6mm Arm Thickness Carbon Fiber Frame Kit for RC Drone FPV Racing
Notice: The camera showed in photos is not included.
Specification:
Item Name: 215mm / 230mm Wheelbase Frame Kit
Model: AX215 V2
Wheelbase: 215mm ( Front ) ; 230mm ( Back )
The Thickness of Arm Plate: 6mm
The Width of Arm Plate: 7.5mm
The Height of Aluminum Standoff: 28mm
Weight: 80g
Camera Mounting: Micro Series Camera ( 19mm )
Recommend Parts:
Flight Controller & ESC: 30.5x30.5mm FC ESC Flytower
Brushless Motor: 22-24 22XX 24XX Series Motor
Propeller: 5 Inch Prop
Camera: 19mm Micro Series Camera
Lipo Battery: 3S / 4S 1300-1500mAh Lipo
The following parts are suitable: ( Not Included)
FC & ESC Flytower: 30.5x30.5mm DYS F4 Pro FC & F30A BL_S 4in1 ESC
Brushless Motor: DYS Wu 2206 2400KV/ 2700KV 3-4S Motor
Propeller: Kingkong 5040 5 Inch 3-Blade Propeller CW & CCW
Camera: RunCam Micro Swift 2 600TVL 1/3 CCD OSD Camera
Package Included:
1x AX215-V2 Frame Kit
