AWESOME TS-195 195mm F3 FPV Racing Drone PNP /w 5.8G 40CH VTX 800TVL HD CCD 4-in-1 BLHeli_S 20A ESC - 180.00 €

AWESOME TS-195 195mm F3 FPV Racing Drone PNP /w 5.8G 40CH VTX 800TVL HD CCD 4-in-1 BLHeli_S 20A ESC
Seller: Banggood,
Free shipping aviable, Registered postage from 25 €


AWESOME TS-195 195mm F3 FPV Racing Drone PNP /w 5.8G 40CH VTX 800TVL HD CCD 4-in-1 BLHeli_S 20A ESC

Flat Arm


28 Degree Curved Arm









Notes:
-This is the PNP (Plug and Play) version that comes without battery, charger, receiver or remote control.
-This version needs to assemble by youself.

Specification:
Brand name: AWESOME
Item name: TS-195 195mm FPV Racing Drone PNP
Wheelbase: 195mm
Arm thickness: 3.5mm
Size: 225*225mm
Weight: 250g (not including battery)
Brushless motor: 2205 2600KV
Brushless ESC: 4-in-1 BLHeli_S 20A
Flight controller: AWESOME F3

Video Transmitter:
Frequency: 5.8GHz
Channels: 40 (including RaceBand)
Power: 25 / 200 / 400mW switchable

Camera:
Lens: 2.8mm
Resolution: 800TVL
TV system: PAL
Sensor: 1/3 Super HAD II CCD
Power input: 5 - 22V DC

Brushless Motor (CCW, CW):
Material: 420F stainless steel shaft
KV: 2205-2600KV
Configuration: 12N 14P
Maximum thrust: 440g/piece
Battery: 2-4S
diameter: 3mm
Weight: 26g/piece

Flight controller:
Item name: AWESOME F3

ESC:
Firmware: BLHeli-S
Continuous current: 20A
Peak current: 40A
Processor: EFM8BB2

Feature:
-Two sets of 3.5mm thick carbon fiber arms, including flat ones and 28-degree curved ones
-New lightweight carbon fiber, 30% lighter than the traditional material
-True "X" configuration with perfect center of mass, low profile design
-F3 flight control system with integrated 5.8G VTX and 4-in-1 BLHeli - S ESC
-5.8G real-time image transmission, 40-channel wide coverage, 25 / 200 / 400mW switchable
-Its 800TVL HD CCD camera has 40-degree adjustable angle and supports low illumination

Package included:
4*flat arm
4*curved arm
1*body frame
4*motor (2*CCW, 2*CW)
4*motor protective frame
1*flight controller
1*4-in-1 BLHeli_S 20A ESC
1*FPV camera
1*antenna
8*5045 tri-blade propeller
