Main Features:
- High TG PCB, blind vias, supper discharge capability
- With top Japanese capacitor and MOS tube, it supports up to 4S voltage input
- An ESC can handle 40A electric current at maximum
- Has the same PCB board supplier as the DJI's
Specifications:
MPU: EFM8BB2
Continuous current: 20A x 4
Burst current: 40A x 4
BEC: 5V 500mA
RPM: 70000
Drive signal: PWM / Oneshot125 / Oneshot42 / Multishot
Firmware: BLHeli - S 16.X
Recommended motor: 1104 / 1306 / 2204 / 2005 / 2006
Specification
General |
Brand: AWESOME
Type: ESC |
|---|---|
Dimension and Weight |
Product weight: 0.012 kg
Package weight: 0.044 kg Product size (L x W x H): 3.50 x 3.50 x 2.00 cm / 1.38 x 1.38 x 0.79 inches Package size (L x W x H): 9.00 x 12.00 x 3.00 cm / 3.54 x 4.72 x 1.18 inches |
Package Contents |
Package Contents: 1 x 4-in-1 ESC |
