MCU: STM32F405 , GRT6, 8K

Sensor:MPU6000

Input Voltage: 2-6S Lipo

- BEC Output: 5V 3A

- Integrated with OSD, support BF Ground Station adjust OSD

- Built-in Current Sensor, can monitor current
- Without Blackbox

Fimware out from factory: betaflihgt_3.2.0_OMNIBUSF4OSD

Receiver: Support PPM, SBUS, IBUS, DSM2/ DSMX Receiver

Size: 42x36mm
Mounting Hole: 30.5x30.5mm

Weight: 9.4g

Instruction for diagram pciture:
1. M1-M4 : ESC Power Cable
2. V+ & V-: ESC's "+" & "-"
3. BOOT button: to flash firmware
4. +5V: output 3A, can connect VTX, Camera and receiver
5. RX6 (S): Connect SBUS Receiver
6. RX1 (D): Connect DSM2/DSMX/IBUS Receiver
7. PPM: Connect PPM Receiver
8. RX3 , TX3: Series UART 3
9. Buz+ & Buz- : Possitive Buzzer "+" and "-"

Package included:
1x Omnibus F4 Flight Controller
4x Anti-vibration Rubber Shock Balls
