Aomway 11dbi 7 Turn 5.8GHz Helical Antenna (RHCP)
Aomway released their new 5.8GHz, 7 Turn 11dbi tuned reflector base helical antennas.
The Aomway 7 is supported by a precision cut glass fiber frame and PCB tuned reflector. The antenna includes a flexible coaxial adapter letting you achieve virtually any installation angle of your setup.
Helical antennas are designed for maximum range, having a tighter focus than an Omni or patch style antenna. Helical antennas also have a broader “tune” range and have great gain across the entire 5.8GHz band.
Note: Helical antennas have a narrower focus for further range, so it's recommended to be used in a diversity system and or antenna tracker setup for the ultimate in video lock and range.
Description:
Bandwidth: 5645-5945Mhz
Gain: 11dbi
Cross polar rejection: >10dbi
Connector type: inner hole or inner needle
Polarity: Right Circular Polarization
Weight: 10g
Impedance: 50ohm
Standing wave <=1.4
Material : fiberglass
Features:
Perfectly compatible with all 32ch of the 5.8GHz range.
All frequency channel standing wave less 1.3.
PCB board as reflection board, effectively improves antenna gain.
High self-recovery function
Supported coil
Flexible adapter
Package included:
1 x Aomway Helical Antenna
