Specification:
Brand name: AIKON
Item name: AK32PIN 4 IN 1 35A 2-6S Blheli_32 Brushless ESC
Battery: 2-6S
Constant Current: 35A
Burst Current: 45A
BEC: 5V/3A
Firmware: Blheli_32
MCU: STM32PIN F0
Bootloader: Yes
Signal wire length: 100mm
Battery wire length: 150mm
Weight( with/wire): 15g
Feature:
BLHeli_32 code base
Programmable PWM frequency of up to 48KHz
Auto-timing for higher efficiency and reliability
Analog Voltage/Current sensing
Adjustable “Brake on Stop” force
Improve direction change in Bidirectional mode
One current sensor to measure the total amp draw and telemetry functions.
ESC Telemetry (Voltage and RPMs and current)
Configuring from FC using DShot commands
Programmable sine modulation mode
Programmable soft bidirectional mode
Programmable autonomous periodic (every 32ms) telemetry mode
Hardware noise filter on the signal input
Package Included:
1 x AK32PIN 4 IN 1 35A 2-6S Blheli_32 Brushless ESC
