Specification:
Item name: Acro 3 Inch frame kit
Wheelbase: 164mm
Unibody Main plate = 3mm bi-axial Toray Carbon Fiber
Side plates (w/adjustable FPV cam placement) = 2mm bi-axial Toray Carbon Fiber
Battery plate (w/optional top mount FC holes) = 1.5mm bi-axial Toray Carbon Fiber
Hardware = Stainless Steel
Frame Dampeners = Custom Poly-urethane
Motor to Motor (diagonal) = 164mm
Motor to Motor (front to back/side to side) = 115mm
Overall Frame size = 141x141mm
Dry Frame Weight = 52.4g
Motor bolt pattern = 12x12mm
Motor c-clip hole = 6mm
standoff: 23mm
Recommended parts (not included)
- Flight control: Omnibus STM32F4 F4 HGLRC XJB F428 AIO Flytower
- Motor:11XX Eachine 1104 6000KV Racerstar BR1104 7000KV
- ESC: 10A-20A Racerstar Mini RS12Ax4Racerstar RS20Ax4
Package included:
1 x full frame(m2 hole for motor)
