A Pair 40KM Ultra Long Range RDF 900 915MHz 3DR Radio Telemetry Modem For Pixhawk PX APM Paparazzi - 169.00 €

A Pair 40KM Ultra Long Range RDF 900 915MHz 3DR Radio Telemetry Modem For Pixhawk PX APM Paparazzi
Seller: Banggood,
Free shipping aviable, Registered postage from 25 €


40KM Ultra Long Range RDF 900 915MHz 3DR Telemetry Radio Modem For Pixhawk PX APM Paparazzi
Description
Frequency Range: 902 - 928 MHz
Output Power: 1W (+30dBm), controllable in 1dB steps ( +/- 1dB @=20dBm typical )
Air Data transfer rates: 4, 8, 16, 19, 24, 32, 48, 64, 96, 128, 192 and 250 kbit/sec ( User selectable, 64k default )
UART data transfer rates: 2400, 4800, 9600, 19200, 38400, 57600, 115200 baud ( User selectable, 57600 default )
Output Power: 1W (+30dBm)
Receive Sensitivity: >121 dBm at low data rates, high data rates (TBA)
Size: 30 mm (wide) x 57 mm (long) x 12.8 mm (thick) - Including RF Shield, Heatsink and connector extremeties
Weight: 14.5g
Mounting: 3 x M2.5 screws, 3 x header pin solder points
Power Supply: +5 V nominal, (+3.5 V min, +5.5 V max), ~800 mA peak at maximum power
Temp. Range: -40 to +85 deg C, tested operational from -73 to +123 deg C.
Package Included
2 x 915MHz Module
4 x Antenna
1 x USB Cable
1 x Wire
