Specification:
Brand Name: Racerstar
Model: SPROG X 2206
Item Name: 2206 2300KV 3-5S Brushless Motor
Motor KV: 2300KV
Quantity: 2 CW Screw Thread & 3 CCW Screw Thread
Idle Current (Io/10V): 1.52A
Battery: 3-4S lipo battery
Net Weight: 34g
36g ( with nut )
Quantity: 2 CW Screw Thread & 3 CCW Screw Thread
Idle Current (Io/10V): 1.52A
Battery: 3-4S lipo battery
Net Weight: 34g
36g ( with nut )
Max. Con. current: 38A
Max.Con. power: 608W
Configu-ration: 12N/14P
Motor Resistance (RM): 0.0372â¦
Max thrust: 1287g (4S/5")
Stator Diameter: 22mm
Stator Thickness: 6mm
Motor Diameter: 27.7mm
Motor Resistance (RM): 0.0372â¦
Max thrust: 1287g (4S/5")
Stator Diameter: 22mm
Stator Thickness: 6mm
Motor Diameter: 27.7mm
Shaft diameter: M5
Motor Body Length: 18.7mm
Overall Shaft Length: 33.7mm
Bolt holes spacing: 16/19mm
Bolt thread: M3
Recommend Propeller: 5 / 6 Inch
Overall Shaft Length: 33.7mm
Bolt holes spacing: 16/19mm
Bolt thread: M3
Recommend Propeller: 5 / 6 Inch
CW screw thread motor comes with Siliver cap
CCW screw thread motor comes with Black cap
Package Included:
2x 2206 2300KV CW Motor
3x 2206 2300KV CCW Motor
1x bag of Screws
Package Included:
2x 2206 2300KV CW Motor
3x 2206 2300KV CCW Motor
1x bag of Screws
