Description:
Item Name: Signal Loss Alarm
Charging Voltage: 5-8V (suitable for HV ESC)
Dimension: 26.5x23.6mm
Weight: 7.3g
LED Indicator:
Red: Charging
Green or Red&Green Alternate Flashing: Fully charge
Features:
- Built-in rechargeable button lithium battery, it can alarm normally even if the model battery is disconnected.
- Sound and light alarm at the same time.
- Support remote alarm via remote control.
- Alarm will be actived after 1 minute no remote control action (Only works when the servo channel is connected)
- Alarm will be actived if no signal on the remote control for 1 minute.
- Alarm will be actived if no signal on the remote control for 1 minute.
- Simple and convenient charging method, more convenient to use. Charging for 10 minutes, continuous alarm for 1 hour.
- Optimized charging module to make charging safer and more efficient. (Charging voltage, 5-8V, suitable for high voltage ESC.)
Use Method:
Package Included:
1x Signal Loss Alarm
Use Method:
1. Turn on the power switch, the buzzer will ring three times, "DI,DI,DI".
2. The alarm will be actived after 1 minute does not move the joystick, only works when the servo channel is connected.
3. The module will alarm after 1 minute when the model battery is powered off.
4. The device will alarm after 1 minute if the remote control has no signal.
Charging Method:
1. The product can be charged while using.
2. Turn the switch to the off state and directly connect the ESC to the MODE interface to charge. (Charging voltage, 5-8V, suitable for high voltage ESC.)
Package Included:
1x Signal Loss Alarm
