5.8G 48CH 25mW VTX & 1/4 Inch CMOS 600TVL Camera NTSC/PAL for Revenger55 RC Drone FPV Racing





VTX:




Camera:


Specification:
Item Name: 5.8G 48ch 25mw video transmitter
Frequency band: 5362~5945MHz
Channels: 48ch
Modulation type: FM
Channel SEL.: Touch Switch
Channel Indicate: CH1~CH8 Channel indication with 8LEDS and A~F frequency group Indicate with 6LEDS
Transmit power: 13±1dBm 25mW
Frequency control: PLL
All harmonic: Max -50dBm
Frequency Stability: ±100KHz (Typ.)
Frequency precision: ±200KHz (Typ.)
Channel Carrier error: 1dB
Antenna impedance: 50 Ω
Dimension:20mm*17mm
Weight:2.6g
Supply Voltage:3.2v~5.5v

Item Name: 1/4 Inch CMOS 600TVL Camera NTSC/PAL
Video Format: NTSC/PAL
Image Resolution: PAL:720X540/NTSC:640X480
Sensor:1/4 inch CMOS
LENS ANGEL: H:120°/V:100°
Supply Voltage:3.2v~5.5v
Dimension:15mm*13mm
Weight:1.8g

Package included:
1x 5.8G 48ch 25mw video transmitter
1x 1/4 Inch CMOS 600TVL Camera
