4X Chaoli CL-615 6x15mm Coreless Motor for 90mm-130mm DIY Micro FPV RC Quadcopter Frame Blade Inductrix

Description:
Motor Diameter: 6mm
Motor Length: 15mm
Shaft Diameter: 1.0mm
Cable Length: 60mm
Weight: about 1.8g
Motor wire: Clockwise Motor(With Red Blue), Anti-clockwise Motor(With Black White)
Option: With 1.25mm JST plug
Quantity: 4 pcs (2 CW and 2 CCW)

1.Operating condition
Rated voltage 3.7V DC Direction of rotation CW and CCW Operating voltage range DC2.0-4.2V DC perating temperature range -10-50°C Motor position all position
2.Mearsuring condition
Motor position horizontal or vertical Power supply regulated DC power supply assuring unquestionable measuring regulated DC power supply assuring unquestionable measuring 10-30°C 30-95%
If the judgment is questionable,Measurent is to be made based on JIS Standard Testing Condition(20+2°C,65+5% ) Direction of rotation viewed from output shaft side
3.Electrical characteristics
Items Specification Standard value NO Load speed 55000rpm±12% 55000 rpm NO Load current 160mA max 95mA Starting voltage 0.8V max 0.5V DC Stall current 2312mA ± 5% 2312mA Terminal resistance 1.6Ω ± 5% 1.6Ω Insulation resistance 10MΩ min AT 250V DC between
motor terminal and case Mechanical noise
Under rated voltage 60 DB(A) max 53dB(A)
Cautions:
1) Please use the motor in this technology index range for the performance of the motor is affected by environmental temperature seriously.
2) It is not allowed to operate in the high temperature with high humidity, and not allowed to contact with corrosive liquid and corrosive gas,should not to be stored and without running Continuously for more than six months.
3) Do not lock the motor shaft while the electric is on. The motor will be burnt out after the motor shaft was locked for more then 1 second.
4) Do not hit the motor directly.

Package included:
2 x CW motor
2 x CCW motor
