Specification:
Operating Frequency: 5.8GHz
Operating Frequency: 5.8GHz
Bandwidth range: 500MHz(5.55-6.05GHz)
Match: return loss (S11) <- 20dB
Matchin: RL(S11)<-20dB
VSWR: <1.22 at 5800GHz
Axial Ratio: <1.3
Radiant efficiency: 95%
interface: SMA / RP-SMA Male
Weight: 8 g
Features:
1. Axis ratio less than 1.3, standing wave ratio 1.2
2. It weighs only 8 grams, PC material shell wrapped to avoid PCB damage
Package included:
2x Antenna LHCP SMA
OR 2x Antenna LHCP RP-SMA
Features:
1. Axis ratio less than 1.3, standing wave ratio 1.2
2. It weighs only 8 grams, PC material shell wrapped to avoid PCB damage
3. "Pagoda II" is based on Maarten Baert optimized circular polarized antenna design
4. Its structure consists of three layers of 1 ounce copper foil embedded in the PCB,
replacing the original typical of the wire structure components (this structure is easy to break)
replacing the original typical of the wire structure components (this structure is easy to break)
2x Antenna LHCP SMA
OR 2x Antenna LHCP RP-SMA
