2838 Sensorless Waterproof Motor 3600/4500KV 35A ESC For 1/12 1/14 Cars

Description:

Motor Features:
- 4 pole 12 slot hi-torque motor design
- CNC machined 6061 T6 billet aluminum heatsink can
- High purity copper windings maximizes efficiency
- High RPM ABEC 5 oversized bearings
- Universal fit, fits all 1/12, 1/14, 1/16, 1/18 brushless cars; multi-mounting system for M2.5 screws
- Precision balanced rotor, smoothness for best reliability and maxium RPM

Motor Specification:
Product Watts Max Voltage Max Amps Rotor Poles IO Resistance KV
(RPM/Volt6) Max RPM Length Diameters Weight
(g) Shaft
(mm) Length of Extend Shaft Connector 2838 600 12V 50A 4 1.8A 0.0285 4500 50000 38mm 28mm 95 ï¿ 3.175 15mm 3.5mm gold 2838 600 14V 43A 4 1.4A 0.0415 3600 50000 38mm 28mm 95 ï¿ 3.175 15mm 3.5mm gold
ESC Features:
- Specially desighed for RC car with excellent start-up, acceleration and linearity feartures
- Compatible with sensorless brushless motor
- The strong resistant current capability, excellent heat dissipation
- Multiple protection features: low voltage cut-off protection for lithium or nickel battery / over-heat protection / throtttle signal loss protection / motor blocked protection
- Easily programmed and compatible with pocket-sized program card

ESC Specifications:
Model 35A Cont. Current/Burst Current 35A/120A Motor Type Sensorless Brushless Motor Suitable Car 1/18, 1/16, 1/14, 1/12 Suitable Brushless Motor ≥12T Resistance 0.003ohm Battery 2-3 cells Lipo
4-9 cells NiMH BEC Output 5V/2A
(analog mode) Dimension 25*30*18.5mm
Package Included:
1 X Motor
1 X ESC
1 X Instruction
