2 PCS 3Bhobby 3B-R 1106 Brushless Motor 6000KV 7500KV 2-3S For RC Drone FPV Racing Multi Rotor - 21.00 €

2 PCS 3Bhobby 3B-R 1106 Brushless Motor 6000KV 7500KV 2-3S For RC Drone FPV Racing Multi Rotor
Seller: Banggood,
Free shipping aviable, Registered postage from 25 €


2 PCS 3Bhobby 3B-R 1106 Brushless Motor 6000KV 7500KV 2-3S For RC Drone FPV Racing Multi Rotor

Description:
Brand name: 3BHOBBY
KV: 6000KV/7500KV
No.of cells(Lipo): 2S-3S
Stator diameter: 11mm
Stator length: 6mm
Shaft diameter: 1.5mm
Motor dimension (Dia.*Len): Φ14.2×16.5mm
Weight: 5.9g (excluding cable)
Wire szie: 28AWG 80mm
Recommend propeller: Gemfan 2-3″
Recommend ESC: 12-20A
Suit for: 90-110 frame
Specifications DATA
Motor KV 6000KV 7500KV
Stator Diameter 11mm 11mm
Stator Thickness 6mm 6mm
No.of Stator Arms 9S 9S
No.of Rotor poles 12P 12P
No-load Current(A/4V) 0.4A 0.6A
Motor Resistance 185mΩ 122mΩ
Max Continuous Current 9.5A 11.39A
Max Continuous Power 113W 90.9W
Weight 6.5g 6.5g
Rotor Diameter 14.2mm 14.2mm
Shaft Diameter 1.5mm 1.5mm
Body Length 14mm 14mm
Overall shaft Length 16.5mm 16.5mm
No.of Cells(Lipo) 2~3S 2S
ESC 12~20A 12~20A
Recommended Prop(inch) 2~3Inch 2~3Inch
Wire Szie 28AWG 80mm 28AWG 80mm

Package included:
2 x 1106 motor
12 x round head hex socket screws M2*4
