Item brand:HGLRC-Flipsky
Item name:Anti-spark Switch
Item size:40mm*32mm
Weight:120g,with packaging
Specification:
V1.5
4 laye*3oz copper=12oz copper
IRFS7730TRL7PP Mosfets
Max continuous amperage: Depends on the fuse, The maximum current value 400A
Max voltage: 13S (60V)
PCB Dimensions: 40mm*32mm
Pre-Soldered
Electric spark hazards:
Burning the contacts, making the circuit contact badly, and damage the circuit;
Sparks may cause damage to electronic components (such as integrated circuits) through the circuit;
In some spark-sensitive areas, such as gas plants or places where flammable gas is installed, a small spark may cause explosions.
Function of anti-spark switch:
Effectively and safely protect the power contact from oxidation caused by electric spark burn and the electronic components of integrated circuits from breakdown; and the occurrence of an electric spark which may cause explosion is prevented.
Effectively extend the use of electronic products
Package included:1XAnti-spark Switch(not include power button)
