16x16mm Racerstar F3D8 F3 FC Built-in Receiver & Star4 4A BL_S DShot ESC & 4 PCS BR0703 0703 10000KV Motor
Specification:
Racerstar F3DB Micro F3 Flight Control ( Moredetails)
Brand Name: Racerstar
Model: F3D8
Item Name: Micro F3 Flight Control Built-in SUBS Receiver for X9D Plus
Size (PCB): 21x21 mm
Weight: 1.4g
1.7g ( including antenna)
Micro F3 Flight Control:
CPU: STM32F3
SPI: ICM-20608-G Accelerometers and Gyroscope
Mounting Hole: 16x16mm, M2
Can support current, voltage monitoring
2.4G Receiver
Channel: 8CH
SUBS Output
Control Range: 200m
Compatible with Frsky X9D Plus Transmitter
Brand Name: Racerstar
Model: Star4
Item Name: 4A 1S Blheli_S 4 In 1 Brushless ESC
Input Voltage: 1S
Con.Current: 4A
Peak Current(10s):5A
BEC:NO
Programming :YES
Net Weight: 1.35g ( not including cable)
Size(PCB): 21x21mm
Mounting Hole: 16x16mm , M2
-D-shot 600 ready in default
-Support D-shot150, D-shot300, Oneshot125 and Multishot
BR0703 10000KV 1-2S Motor ( More details)
BR0703 10000KV 1-2S Motor ( More details)
Brand: Racerstar
Item No: BR0703 10000KV Brushless Motor
Height: 16.2mm
Width: 10mm
Weight: about 1.9g
Shaft: φ1.0mm
KV (rpm/V): 10000
Voltage: 3.7-7.4V
Battery: 1-2S lipo battery
Usage: for 60-100 class RC Mini Multirotor
Package Included:
1x Racerstar F3D8 Micro F3 FC buit-in Receiver Module
1x Racerstar Star4 4A 4 in 1 Dshot ESC
4x Racerstar BR0703 1000KV Motor
