Specification:
Mount hole:15mm*15mm
Size: 20mm*20mm*23mm
Weight: 10g
Teenycube Frsky D8 Compatible 2.4G 8CH Receiver:
Frequency range: 2.403-2.479Ghz
Channels: 8CH
Work mode: D8 Mode
Output: SBUS/PPM Switchable
Antenna length: 50mm
No ground interference ( Transmitting and receiving 1 m from the ground): >200m
Working current: 80mA
Dimensions: 20*20*5mm
Weight: 1.2g
Compatible with FRSKY ACCST
Compatible with X9D(Plus)DJT/DFT/DHT
Teenycube F3 6DOF Flight Controller:
STM32 F303 MCU
Firmware version: Betaflight 3.1
Firmware target: Omnibus
ESC Dshot protocol compatible(Need not modify)
SBUS/PPM/DSM2/DSMX input (Pin headers)
4PWM output (Pin headers)
Super Tiny Only 20x20mm, mount holes 15x15mm M2 screw
SPI Sensor MPU6000
2-4S Lipo Direct power
5V@1A BEC
3.3V output for spectrum Satellite Receiver
Built-in PDB
LED Strip solder pad ready
Buzzer solder pad ready
Weight: only 1.6g
Best for 60mm-80mm brushless frame
Teenycube 6A BLHeli_S Dshot 2 In 1 ESC:
Model:BS06D 2in1
Con. Current: 6A
Peak Current(10s): 10A
Input Voltage: 2S Lipo
BEC: No
Programming : YES
Cleanflihg/Betaflight pass-through ready
Firmware: Blheli_S 16.5
Net Weight: only 1.7g (Not include wire)
Size: 20*20mm
Mount hole: 15mm*15mm M2
Features:
-STM32 F303MCU + BLHELI_S ESC make your Operating feel more stabilly and silky
-Jaw-dropping flight performance
-LED_STRIP solder pin
-BUZZER solder pin
-Betaflight support
-Acro mode / Air mode /Angle mode support
Package included:
1 x Teenycube Frsky D8 Compatible 2.4G 8CH Receiver
1 x Teenycube F3 6DOF Flight Controller
2 x Teenycube 6A BLHeli_S Dshot 2 In 1 ESC
