Description:
Item Name: AV Video Switcher Module
Input Power: 5V-10V
Input Control: 1-2MS PWM
Channel: 2CH, 3CH (optional)
Size: 16*16mm
Weight: 0.8g
Indicator:
- Steady light
- Fast flash
- Slow flash
Features:
- Two/Three channel electronic video switcher, which can control 2 (3) cameras or DV AV signals through the remote control.
- Switch to the OSD or video transmitter separately to give your FPV a different angle of view.
- Dedicated video switching IC, lossless picture quality, ultra-small internal resistance.
- Can also be used as an electronic switch, electronic ignition, shutter trigger, air switching, transmitter channel, and etc.
- Can be connected to any channel of the receiver to use (PWM), actually using two (three) gear switches or knob channels to use.
Note:
Please pay attention to the wiring sequence when using.
The video switching module itself is powered by the receiver 5V (also can be powered separately 5-10V).
Do not connect more than 10V to the video switching module.
Package Included:
1x AV Video Switcher Module
2x Pin
