Description:
EFFIO is a digital signal processor (DSP) developed by Sony for video surveillance cameras. It can provide high resolution image quality, high signal-to-noise ratio (SNR), and high color reproduction capability for video.
Effio DSP supports NTSC-standard 480K effective pixel CCD, and PAL specification 570K effective pixel CCD. With the Effio DSP and the new CCD, the resolution of more than 650 TVL levels can be achieved. Compared with the standard camera, this method can provide a clearer image. Its color signal processor provides ideal color brightness and concentration balance.
The Effio DSP supports Wide Dynamic Range (WDR) CCDs, which can also display clear images in environments where backlight and brightness contrast are extremely high. Effio DSP can improve the performance of "Super HAD CCD II". Sony's image sensors have a high degree of stability and sensitivity and are widely deployed in surveillance cameras.
Effio DSP combines 2D and 3D noise reduction functions to achieve dynamic resolution even when shooting moving objects. In addition, the Effio DSP incorporates peripheral circuitry that not only reduces camera size but also reduces power consumption.
The Effio DSP supports Wide Dynamic Range (WDR) CCDs, which can also display clear images in environments where backlight and brightness contrast are extremely high. Effio DSP can improve the performance of "Super HAD CCD II". Sony's image sensors have a high degree of stability and sensitivity and are widely deployed in surveillance cameras.
Effio DSP combines 2D and 3D noise reduction functions to achieve dynamic resolution even when shooting moving objects. In addition, the Effio DSP incorporates peripheral circuitry that not only reduces camera size but also reduces power consumption.
Specifications:
Item Name: EFFIO-E 4140+811 CCD Motherboard Chip
CCD Type: 1/3" SONY SUPER HAD CCD
Signal system: PAL / NTSC
Pixels: PAL - 976(H)x582(V), NTSC - 976(H)x494(V)
Pixels: PAL - 976(H)x582(V), NTSC - 976(H)x494(V)
Processing Chip: CXD4140GG+D5148GG
Synchronization: Internal
Synchronization: Internal
Horizontal Clarity: 700TVL
Minimum Illumination: 0.01LUX/F1.2
Minimum Illumination: 0.01LUX/F1.2
Digital Noise Reduction: Yes (2D)
OSD Menu: Yes
WDR: Yes
Automatic Gain: Yes
Horizontal Mirror: Yes
Backlight Compensation: Yes
WDR: Yes
Automatic Gain: Yes
Horizontal Mirror: Yes
Backlight Compensation: Yes
Electronic Shutter: Yes
White Balance: Yes
Gamma Correction: 0.45
Signal to Noise Ratio: ≥50dB
White Balance: Yes
Gamma Correction: 0.45
Signal to Noise Ratio: ≥50dB
Video Output Amplitude: 1.0Vp-p/75Ω
Operating Voltage: DC12V 1000mA
Operating Current: 45±5mA
Working Temperature: -40°C - 105°C
Size: 32*38mm
Weight: 15g
Operating Current: 45±5mA
Working Temperature: -40°C - 105°C
Size: 32*38mm
Weight: 15g
3P Video Wiring Diagram (From top to bottom):
Yellow - Video
Black - GND
Red - Power
Black - GND
Red - Power
Features:
Single board, low illumination.
Color to Black (D/N), IR Sensitive.
Support OSD menu function and eight languages.
With lightning protection,safe to use.
Package Included:
1x Motherboard
Color to Black (D/N), IR Sensitive.
Support OSD menu function and eight languages.
With lightning protection,safe to use.
Package Included:
1x Motherboard
