Specifications:
Image sensor: 1/3" SONY 510 pixels Exview HAD CCD sensor]
SIignal system: PAL:633+4140+5148 NTSC:632+4140+5148
Pixel: 510(H)×582(V) 510(H)×494(V)
Synchronization Mode: Internal synchronization
Minimum Illumination: 0.001LUX/F1.2
Horizontal Clarity: 600TVL
Gamma correction: 0.45
S/N Ratio: ≥50
Lens: Automatic/Manual
Image adjustment: Mirror/Brightness/Contrast/Sharpness/Hue/Gain
ATR: open/close
Day/Night: Auto/Color/Black and White
Backlight compensation: off/backlight compensation/brightness compensation
Language: Chinese/English/Japanese/German/French/Russian/Portuguese//Spanish
Digital Noise Reduction: Noise Reduction Mode / Y Level / C Level
White balance: ATW/single press/user 1/user 2/suppress color scroll/manual/single press lock
Electronic shuttle: Automatic/Manual (OSD adjustable, multi-level optional)
Camera ID: open/close
Privacy: open/close
Video output: Composite signal Y/C output 1.0Vp-p 75Ω
Power supply: DC12V
Working current: 50mA±5mA
Working Temperature: -20°C--+60°C
Humidity: Internal relative humidity 85%RH
Features:
Single board, low illumination.
Color to Black (D/N), IR Sensitive.
Support OSD menu function and eight languages.
With lightning protection,safe to use.
Package Included:
1x Motherboard
