Specification:
Image Sensor: 1/3" SONY Super HAD II CCD
Horizontal Resolution: 600TVL
Lens: 2.1mm Lens(M8) FOV160° / 2.3mm Lens(M8) FOV145°
Signal System: PAL / NTSC
S/N Ratio >60dB(AGC OFF)
Electronic Shutter Speed PAL:1/50 ~ 100,000; NTSC:1/60 ~ 100,000
AutoGain Control(AGC): YES
Back light compensation(BLC): YES
Min.illumination: 0.01Lux/1.2F
WDR D-WDR
DNR 2DNR
Day/Night Color / Auto / B&W
Power: DC 5 to 36V
Net weight: 6.6g
Dimensions: 19mm * 19mm * 19m
Features:
- 600TVL high picture quality
- 1/3" SONY SUPER HAD II CCD
- Nextchip 2040 DSP
- Powerful OSD menu
- D-WDR (Wide Dynamic Range)
- 2D-DNR (Digital Noise Reduction)
- Low Power Consumption(70mA)
- Mirror function
- Privacy areas: 8 areas
- Low illumination: 0.01Lux
- 2.3mm 2.1MM Lens
- Low Power Consumption
- Suitable for FPV
Package included:
1 x 1/3'' CCD 2.1mm/2.3mm 600TVL HD Wide Angle FPV Camera
2 x Cables
Package included:
1 x 1/3'' CCD 2.1mm/2.3mm 600TVL HD Wide Angle FPV Camera
2 x Cables
